4 Core + Earth (5G), 2.5mm², TCW, PVC 90°C, SWA, 0.6/1KV, Circular TPS Cable (MASCP5G2.5SWA)

APPLICATION:
For mains and sub mains power circuits where mechanical protection is required. Fixed application. Suitable for direct burial.

Voltage 0.6/1KV
Conductor Stranded Tinned Copper Conductor
Insulation PVC, V90
Core Colours Red, White, Blue, Black, Green/Yellow
Separator PET Tape or Non-Woven Tape
Bedding SPVC, 5V-90, Black
Armour Galvanized Steel Wire
Sheath SPVC, 5V-90, Black
Operating Temp. -20°C to +90°C
Max. DC Resistance @ 20°C (Ω/KM) 7.41

Standards AS/NZS1125 , AS/NZS3008, AS/NZS3808 , AS/NZS5000.1, AS/NZS60079.14, IEC60332-1-2, IEC 60332-3-22, RoHS Compliant
